ข้อมูลด้านเทคนิค
| Size (Model No.) | Small (PTK-440) | Medium (PTK-640) | Large (PTK-840) | X-Large (PTK-1240) |
| Technology | EMR (Electro magnetic resonance) | |||
| Physical Size (W x D x H) |
309 x 208 x 12 mm | 370 x 254 x 12 mm | 474 x 320 x 14 mm | 623 x 462 x 28 mm |
| Tablet Weight | 0.7 kg (1.54 lbs) | 1.0 kg (2.20 lbs) | 1.8 kg (3.96 lbs) | 3.5 kg (7.72 lbs) |
| Active area (W x D) | 157.5 x 98.4 mm | 223.5 x139.7 mm | 325.1 x 203.2 mm | 487.7 x 304.8 mm |
| Active area (inches) | 4 x 6 | 6 x 9 | 8 x13 | 12 x19 |
| Surface Sheet | 173.4 x 111.4 mm | 233.6 x 146.6 mm | 335.4 x 210.4 mm | 493.4 x 328.2 mm |
| ExpressKeys | 6 | 8 | ||
| ExpressKey Displays | --- | 2 (one beside each set of four Express Keys) | ||
| ExpressKey Display Resolution | --- | 64 x 128 dots | ||
| Touch Ring | 1 Touch Ring with 4 settings switchable via Toggle Button | |||
| Tablet Pressure Levels | 2,048 levels | |||
| Tablet Resolution | 200 lpmm (5080 lpi) | |||
| Accuracy (Pen) | +/-0.25 mm | |||
| Accuracy (Lens Cursor) | --- | --- | +/-0.15 mm | +/-0.15 mm |
| Tilt Sensitivity (all pens) |
+/-50 degrees | +/-60 degrees | ||
| Reading Height (Pen) | 10 mm | |||
| Report rate | 200 pps (points per second) | |||
| Interface | USB | |||
| Bundled Software | Adobe® Photoshop® Elements 6 (Mac)/7 (Win), Corel® Painter™ Sketch Pad, Autodesk® Sketchbook® Express, Nik® Color Efex™ 3.0 Sample Filters, Wacom Brushes |
|||
